Front Drive Axle for YT804 Tractor

Product type: Farm Machinery Axle

Address:NO.257 Kangwang West Road,Feicheng City,

Address:Shandong Province.

Tel:+86.538 2095198   2095186   ;3302973   3302663

After-sale service:+86.538 3302961   2095189   2095178

Fittings department:+86.538 2095198 3302651

Main connection dimensions

Characteristics:

● Two-stage decelerating structure is adopted for steeringdrive axle.universal joint rotating at constant angular velocity is adopted to connet the inner semi shaft with the drive shaft.with the drive shaft.

● Integral-type ductile-iron axle housing with adequaterigidity and light weight is adopted.

● Centrally positioned transmission shaft and swing-typecentral swing pin are adopted.

● Front-wheel steering solely under hydraulic pressure,the steering angle can reach 50。.

● Suitable for 80-100 horsepower four-wheel drive tractorand similar products.

Technical parameter

Maxium input torque
350N.m
Transimssion ration
21.125/23.766/20.042/17.727/16.264
Front-wheel
 positioning
Front-wheel camber
1
Kingpin incl ination angle
730"
Kinpin caster angle
10
Toe-in of front wheel
0-5mm
Steering type
Indepent oil-wey,front-Wheel steering solely under hydraulic pressure
Oscillative angle of front axle
11Front-wheel cmber angle
Maximum steering angle of front wheel
50 able to reach 45,40
Diameter of steering oil cylinder
Ф48
Stroke of steering oil cylinder
200mm
Maximum allowable pressure for steering cylinder
16MPa
Maximun load-carrying capacity
2500Kg
Font-wheel cmber angle
292Kg
Spline parameters
m=2.75,Z=10,a=30
