Front Drive Axle for WZZD75 Loader-digger

Product type: Loader Drive Axle

Address:NO.257 Kangwang West Road,Feicheng City,

Address:Shandong Province.

Tel:+86.538 2095198   2095186   3302973   3302663

After-sale service:+86.538 3302961   2095189   2095178

Fittings department:+86.538 2095198 3302651

Main connection dimensions




Characteristics:

● The advanced overseas technologies on engineering machinery axle are adopted.

● The cast-steel axle housing with great load carrying capacity and adequate rigidity is adopted.

● The centrally positioned transmission shaft and swing-type central swing shaft are adopted.

● The inner structure includes central reducer,transmission differential,end poanetary reducer,etc.

● Centrally positioned steering oil cylinder able to realize convenient and flexible steering.

● Independent oil-way is adopted, steering solely under hydraulic pressure,the steering angle can reach 50°.

Technical parameter

Speed ratio of main reductor
2.462
Maximum steering angle of front wheel
50°
Speed ratio of hub reductor
6
Diameter of steering oil cylinder
65
Total speed ratio
14.77
Stroke of steering oil cylinder
260
Front-wheel
positionin parameters
Front-wheel camber angle
1°30‘
Oil-tube connectr of oil cylinder
9/16-18 UNF-2B
Kingpin indlination angle
7°
Static lodd
237500N
Toe-in of front wheel
0-2
Dynamic load
95000N
Oscillative angle of front axle
11°
Weight
310Kg
