Loader Drive Axle

HOME > PRODUCTS > Product Center > Loader Drive Axle > Loader Drive Axle

Drive Axle for WZD75 Loader-digger

Product type: Loader Drive Axle

Address:NO.257 Kangwang West Road,Feicheng City,

Address:Shandong Province.

Tel:+86.538 2095198   2095186   3302973   3302663

After-sale service:+86.538 3302961   2095189   2095178

Fittings department:+86.538 2095198 3302651

Main connection dimensions

Characteristics:

● Multiple installation dimensions of axle housing are able to meet the respective requirements of users.

● Differential lock is equipped on the main reducer to deal with poor operating conditions.

● Concealed wet-type brake with steady and reliable braking.

● Advanced temperature-control and pressure-sensing technologies for asfe reliable operation of the entire machine.

Technical parameter

Speed ratio of main reducer
2.333
Speed ratio of hub rednctor
6.923
Total speed ratio
16.152
Static load
19000Kg
Dynamic load
7600Kg
Oil-prssure for differential-lock control
1.1-2MPa
Differemial-lock control port
M14×1.5
Driving brake
Number of friction plate pairs on each side
2
Maximum drive-braking moment
  34500N.m
Oil-tube connector
  M10×1
Maximun braking oil-pressure
4.3MPa
Oil-extraction quantity in braking activity
about 25cc
Operating temperature
-40~+130℃
Braking parameters on parking
Maximum tension of pull rod
360daNm
Maximum braking moment
13000Nm
