ZL30S Wet-type Braking Drive Axle

Product type: Loader Drive Axle

Address:NO.257 Kangwang West Road,Feicheng City,

Address:Shandong Province.

Tel:+86.538 2095198   2095186   3302973   3302663

After-sale service:+86.538 3302961   2095189   2095178

Fittings department:+86.538 2095198 3302651

Main connection dimensions


a


Characteristics:

● Two-stage decelerating structure is adopted for drive axle.

● The wheel is the planetary decelerating structure.

● Spiral bevel gears with great load-carrying capacity and high efficiency are adopted for main drive.

● The main reducer is equipped with the common bevel-gear differential mechainsm with simple structure and flexible differential function.

● Ductile iron with adequate rigidity serves as material for axle housing.

● The brake in enclosed multiple-cisc wet-type braking mode,with braking semi shaft,hydraulic pressing,spring release and ideal brake performance,is installed in front of the planetary hub decelerationgears.

Technical parameter

Main transmission ratio
4.222
Transmission ratio at wheel
4.8
Total transmission ratio
20.26
Axle load
18500Kg
Input torque
2300N.m
Braking oil pressure
8.16MPa
 Brake moment
24480N.m
Oil discharge quantity in normal braking
28ml
